2024
| Part Number | Chip Length (mil) | Chip Width (mil) | Structure | Max IDRM (nA) | VDRM (V) | Typ. VTM (V) @Itm =100mA | Typ. VINH(V) | IDS (uA) |
| ST-0182S | 42.50 | 42.50 | Zero crossing | 500 | 800 | 1.60 | 10 | 10 |
| ST-1127S | 40.00 | 40.00 | Non-zero crossing | 500 | 800 | 1.70 | - | - |
| ST-2182S | 42.50 | 42.50 | Zero crossing | 500 | 800 | 1.60 | 10 | 10 |
| Part Number | Chip Length (mil) | Chip Width (mil) | Structure | Res. Range (nm) | Peak Res. WL (nm) |
| ED-MPD1212VB | 12 | 12 | PD | 900-1700 | 1530 |
| ED-MPD1313VB | 13 | 13 | PD | 900-1700 | 1530 |
| ED-MPD1515VA | 15 | 15 | PD | 900-1700 | 1530 |
| ED-MPD25VB | 25 | 25 | PD | 900-1700 | 1530 |
| ED-MPD50VB | 47 | 47 | PD | 900-1700 | 1530 |
| ED-MPD90VB | 86 | 86 | PD | 900-1700 | 1530 |
